商品說明
- 光度輸出: 8,400 流明 (中央部份)；對比度 : 10,000:1
- 解像度: 4,608,000 像素 / 2715 x 1697點
- 採用Laser diode 光源，可長時間使用
- 獨立的 LAN/DIGITAL LINK 終端
- 數據克隆功能
- 獨有的對比度同步和快門同步功能
- 快速開關模式
- 監控軟件和預警軟件
- 多單元亮度和顏色控制
| 一般規格 | |||
| 面板 | 0.67″ 1片式DLP投影機 | ||
| 燈泡 | N.A. (Laser diodes 光源) | ||
| 亮度 | 8,000流明 / 8,400流明(中央部份) | ||
| 鏡頭 | 選配 | ||
| 對比度 | 10,000:1 (Full On/Full Off, Dynamic Contrast Mode: 3) | ||
| 解像度 | 4,608,000 像素 / 2715 x 1697點 (使用平滑像素驅動：開啟) | ||
| 影像大小(對角) | 1.27–15.24 m (50–600 in), 1.27–5.08 m (50–200 in) with ET-DLE055, 2.54–8.89 m (100–350 in) with ET-DLE035, 2.54–10.16 m (100–400 in) with ET-DLE020, 16:10 aspect ratio | ||
| 鏡頭移動功能 | 垂直 +50%, -16% 橫向 +30%, -10% (個別鏡頭移動範圍請參閱宣傳單張) | ||
| 梯型矯正範圍 | Vertical: ±40° (±5° with ET-DLE020, ±16° with ET-DLE060, ±22° with ET-DLE105/ET-DLE085/ET-DLE055, +5° with ET-DLE035), Horizontal: ±15° (±10° with ET-DLE060) (cannot be operated with ET-DLE035/ET-DLE020) |
||
| 重量 | 大約 24.2 kg (包括鏡頭) | ||
| 大小(闊x高x深) | 498 x 200 x 581 mm | ||
| 功率 | 880 W | ||
| 接駁終端 | SDI In : BNC x 1 : 3G/HD-SDI Input HDMI In : HDMI 19-pin x 1 DVI-D In : DVI-D 24-pin x 1 Multi Projector Sync In : BNC x 1 Multi Projector Sync Out : BNC x 1 Serial In : D-sub 9-pin (female) x 1 Serial Out : D-sub 9-pin (male) x 1 Remote 1 In : M3 x 1 for wired remote control Remote 1 Out : M3 x 1 for link control (for wired remote control) Remote 2 In : D-sub 9-pin (female) x 1 for external control (parallel) LAN : RJ-45 x 1 for network connection, 10Base-T/100Base-TX, compliant with PJLink™ (Class 2), Art-Net Digital Link : RJ-45 x 1 for network, DIGITAL LINK connection (HDBaseT™ compliant), 100Base-TX, compatible with Art-Net, PJLink™ (Class 2), Deep Color, HDCP 2.2, 4K/60p signal input USB : USB Connector (Type A) x 1 for Cloning/Wireless Module (output 5 V/500 mA) Expansion Slot : Open slot for SLOT NX compatible interface board |
||
| 燈泡型號 | NA | ||
| 可選購配件 | ET-PKD130H 6-axis, High ceiling mount bracket ET-PKD120H High ceiling mount bracket ET-PKD120S Low ceiling mount bracket ET-PKD130B Projector mount bracket ET-MDN12G10 Interface board for 12G-SDI input ET-MDNHM10 Interface board for HDMI® (HDCP 2.2) input ET-MDNDV10 Interface board for DVI input ET-MDNDP10 Interface board for DisplayPort™ AJ-WM50 series Wireless module ET-YFB200G Digital Link Switcher ET-YFB100G Digital Interface Box ET-UK20 Geometry Manager Pro Software Upgrade Kit ET-CUK10/ET-CUK10P Auto Screen Adjustment Uprgrade Kit ET-SWA100 series Early Warning Software ET-NUK10 NFC Upgrade Kit |
||
| 可選購鏡頭 | 變焦鏡頭 | ET-DLE020 (0.280-0.299:1) ET-DLE060 (0.600-0.801:1) ET-DLE085 (0.782-0.977:1) ET-DLE105 (0.978-1.32:1) ET-DLE150 (1.30-1.89:1) ET-DLE170 (1.71-2.41:1) ET-DLE250 (2.27-3.62:1) ET-DLE350 (3.58-5.45:1) ET-DLE450 (5.36-8.58:1) |
|
| 固定焦距鏡頭 | ET-DLE035 (0.380:1) ET-DLE055 (0.785:1) |
||
| 原裝配件 | 電源線 x 1 無線遙控器 x 1 遙控器電池 x 2 鏡頭蓋 x 1 |
||
