LG 86UL3G-B UL3G Series

  • Brightness(Typ.) : 350 cd/m²
  • Bezel : 21.9 mm (Even)
  • Depth : 93.3 mm
  • Interface : HDMI(3), USB 2.0(2), RS232C In/Out, RJ45 In, IR In, Audio Out
  • Built-in Speaker

商品說明

PANEL

  • Screen Size
    86”
    Panel Technology
    IPS
  • Aspect Ratio
    16 : 9
    Native Resolution
    3,840 x 2,160 (UHD)
  • Refresh Rate
    120 Hz
    Brightness(Typ.,cd/m²)
    350
  • Contrast Ratio
    1,400:1
    Viewing Angle (H x V)
    178 x 178
  • Response Time
    5ms (G to G)
    Surface Treatment (Haze)
    Haze 3%
  • Life Time (Min.)
    30,000 Hrs
    Operation Hours (Hours / Day)
    16 / 7
  • Portrait / Landscape
    No / Yes

CONNECTIVITY

  • Input
    HDMI (3, HDCP2.2), USB 2.0 Type A (2)
    Output
    Audio
  • External Control
    RS232C In/out (4 Pin Phone-Jack), RJ45 (LAN) In, IR In

MECHANICAL SPECIFICATION

  • Bezel Color
    Dark Meteo Titan
    Bezel Width
    21.9 mm (Even Bezel)
  • Weight (Head)
    44.2 kg
    Weight (Head+Stand)
    45.0 kg
  • Packed Weight
    59.0 kg
    Monitor Dimension (W × H × D)
    1,943 x 1,118 x 77.9 mm (Thickest Point 93.3 mm)
  • Monitor incl. Stand Dimensions (W x H x D)
    1,943 x 1,188 x 345 mm
    Carton Dimensions (W × H × D)
    2,116 x 1,261 x 285 mm
  • Handle
    No
    VESA™ Standard Mount Interface
    600 x 400 mm

ENVIRONMENT CONDITIONS

  • Operation Temperature
    0°C to 40°C
    Operation Humidity
    10% to 80%

POWER

  • Power Supply
    AC 100-240V~, 50/60Hz
    Power Type
    Built-In Power

POWER CONSUMPTION

  • Typ. / Max.
    240 W / 325 W
    Smart Energy Saving
    168 W

SOUND

  • Speaker
    Yes

CERTIFICATION

  • Safety
    CB / UL (TBD)
    EMC
    FCC Class “A” / CE / KC (TBD)

SOFTWARE COMPATIBILITY

  • Content Management Software
    SuperSign CMS
    Control and Monitoring Software
    SuperSign Control+/Control
  • Signage365Care
    Yes*
    * The availability of the “Signage365Care” service differs by region.

ACCESSORY

  • Basic
    Remote Controller, Power Cord, Regulation Book, Phone to D-Sub9 Gender, Stand

GENERAL

  • Region
    Global
