商品說明
PANEL
-
- Screen Size
- 86”
- Panel Technology
- IPS
-
- Aspect Ratio
- 16 : 9
- Native Resolution
- 3,840 x 2,160 (UHD)
-
- Refresh Rate
- 120 Hz
- Brightness(Typ.,cd/m²)
- 350
-
- Contrast Ratio
- 1,400:1
- Viewing Angle (H x V)
- 178 x 178
-
- Response Time
- 5ms (G to G)
- Surface Treatment (Haze)
- Haze 3%
-
- Life Time (Min.)
- 30,000 Hrs
- Operation Hours (Hours / Day)
- 16 / 7
-
- Portrait / Landscape
- No / Yes
CONNECTIVITY
-
- Input
- HDMI (3, HDCP2.2), USB 2.0 Type A (2)
- Output
- Audio
-
- External Control
- RS232C In/out (4 Pin Phone-Jack), RJ45 (LAN) In, IR In
MECHANICAL SPECIFICATION
-
- Bezel Color
- Dark Meteo Titan
- Bezel Width
- 21.9 mm (Even Bezel)
-
- Weight (Head)
- 44.2 kg
- Weight (Head+Stand)
- 45.0 kg
-
- Packed Weight
- 59.0 kg
- Monitor Dimension (W × H × D)
- 1,943 x 1,118 x 77.9 mm (Thickest Point 93.3 mm)
-
- Monitor incl. Stand Dimensions (W x H x D)
- 1,943 x 1,188 x 345 mm
- Carton Dimensions (W × H × D)
- 2,116 x 1,261 x 285 mm
-
- Handle
- No
- VESA™ Standard Mount Interface
- 600 x 400 mm
ENVIRONMENT CONDITIONS
-
- Operation Temperature
- 0°C to 40°C
- Operation Humidity
- 10% to 80%
POWER
-
- Power Supply
- AC 100-240V~, 50/60Hz
- Power Type
- Built-In Power
POWER CONSUMPTION
-
- Typ. / Max.
- 240 W / 325 W
- Smart Energy Saving
- 168 W
SOUND
-
- Speaker
- Yes
CERTIFICATION
-
- Safety
- CB / UL (TBD)
- EMC
- FCC Class “A” / CE / KC (TBD)
SOFTWARE COMPATIBILITY
-
- Content Management Software
- SuperSign CMS
- Control and Monitoring Software
- SuperSign Control+/Control
-
- Signage365Care
- Yes*
* The availability of the “Signage365Care” service differs by region.
ACCESSORY
-
- Basic
- Remote Controller, Power Cord, Regulation Book, Phone to D-Sub9 Gender, Stand
GENERAL
-
- Region
- Global
