KEF LSX

Dimension (H x W x D)

240 x 155 x 180 mm (9.5 x 6.1 x 7.1in.)

WEIGHT

3.6kg (7.9lbs)
3.5kg (7.7lbs))

WI-FI NETWORK STANDARD & frequency band

Dual-band 2.4GHz/5GHz
IEEE 802.11a/b/g/n

Driver units

Uni-Q driver array:
HF: 19mm (0.75in.) aluminium dome
LF/MF: 115mm (4.5in.) magnesium/aluminium alloy cone

Inputs

2.4GHz/5GHz Dual-band Wi-Fi network
Bluetooth 4.2 with aptX® codec
TOSLINK Optical
3.5mm Auxiliary Input
RJ45 Ethernet (For network)

Output

AMplifier output power

LF: 70W     HF: 30W

Bluetooth range & memory

10m
8 devices

Bluetooth Frequency

2.402GHz – 2.48GHz

Bluetooth Power

2.5mW (Bluetooth Class 2 Device)

resolution

Input:
Supports up to 192kHz/24bit

Output:
Wireless mode: 48kHz/24bit
Cable mode: 96kHz/24bit

Master and Slave speaker
Connection

Wireless: Propriety 2.4GHz
Wired: RJ45 Ethernet
Depending on connection settings

maximum outpuT(SPL)

102dB

Power Input

100 – 240VAC 50/60Hz

WIreless connectivity

TIDAL

Frequency range

Frequency Range (-6dB)
Measured at 85dB/1m
49Hz – 47kHz (More bass extension)
52Hz – 47kHz (Standard)
55Hz – 47kHz (Less bass extension)
Depending on speaker settings

frequency response

Frequency Response (±3dB)
Measured at 85dB/1m
54Hz – 28kHz (More bass extension)
59Hz – 28kHz (Standard)
69Hz – 28kHz (Less bass extension)
Depending on speaker settings

Third Party Support

Mounting inserts for supporting wall mount
Supports 3rd party remote programme
Supports IP Control

Master Speaker

Slave Speaker
