Barco ClickShare CS-100 Huddle

Wireless presentation system for huddle spaces

Collaborate better, in small teams. Huddle spaces are creative, flexible, straightforward and intuitive spaces where you bring your own device to share, discuss, interact. Quick and easy.

That is why Barco has developed ClickShare CS-100 Huddle. With this wireless presentation system designed for spontaneous collaboration in huddle spaces, users can simply share what’s on their laptop or mobile device, on the presentation screen. No cables, no set-up, no waiting to join in. Focus on what matters.

分類： , ,

商品說明

Turn huddle spaces into vibrant collaboration spaces

The CS-100 Huddle brings quick, creative content sharing to small meeting and huddle rooms. It provides your enterprise a uniform meeting experience from huddle space to boardroom. Anyone – including guests – can connect and share, no need for training. Use the ClickShare App to get the content from your device on the meeting room screen. Make sure to have the latest firmware installed on your Base Unit to enable the best experience with the Desktop App. Or order the ClickShare Button in addition to the package for enriched, straightforward content sharing.

Fit for your company

The CS-100 Huddle is a stand-alone model with an HDMI output, that allows up to 8 users to connect and, with one user sharing at a time. It can also be integrated in the company network and centrally managed, to enjoy a uniform experience from your huddle space to your boardroom. The CS-100 Huddle includes the standard ClickShare security features including encryption, login management, https and the possibility to hide the SSID of the Base Unit’s wireless network.

The CS-100 Huddle is a product created with ISO 27001 certified flows and processes.

Specifications

General specifications

Operating system Windows 7/8/8.1/10 32 & 64 bit
macOS 10.14/10.15 (Catalina)
Android 9 & 10 (ClickShare app)
iOS 11, 12 & 13 (ClickShare app)
Video outputs 1x HDMI 1.2
Output resolution 1920×1080 @60Hz
Audio Via HDMI, analog via Audio Jack 3.5mm
Frame rate Up to 30 fps*
Number of sources simultaneous on screen 1
Number of simultaneous connections 8
iPad, iPhone and Android compatibility Sharing of documents, browser, camera for both Android and iOS devices via ClickShare app
Extended desktop Available for Windows, requires ClickShare Extension Pack.
Authentication protocol WPA2-PSK in stand-alone mode
WPA2-PSK or IEEE 802.1X using the ClickShare Button in network integration mode
Wireless transmission protocol IEEE 802.11 a/g/n
Reach Adjustable with signal strength modulation; max. 30m (100 ft) between ClickShare Button and ClickShare Base Unit
Frequency band 2.4 GHZ and 5 GHz (DFS channels not supported)
Connections 1x Ethernet LAN 100Mbit
1x (back) + 1x (front) USB
Audio analog line out on mini jack socket (3.5mm)
Noise Level Fanless
Temperature range Operating: 0°C to +40°C (+32°F to +104°F)
Max: 35°C (95°F) at 3000m
Storage: -20°C to +60°C (-4°F to +140°F)
Humidity Storage: 0 to 90% relative humidity, non-condensing
Operation: 0 to 85% relative humidity, non-condensing
Anti-theft system Kensington lock
Certifications FCC/CE
Warranty 3 years standard
Google Cast Support Google Cast not supported

*Note*In optimal WiFi conditions with minimal WiFi interference and as measured during our quality validation. Check Network Deployment Guide for more info on WiFi optimisation and ideal configuration depending on your network environment.

ClickShare Base Unit dimensions

Weight 600g / 1.32lbs
Dimensions (HxWxD) 205mm x 115mm x 45mm (Min.) / 8.1” x 4.5” x 1.8” (Min.)
Power consumption Operation: 6W (typical) / 18W (max)
Standby: 2.6W (ECO standby) / 0.4W (Deep standby)
