Aurora VLX-TCW2V-C

4K 1Gbps AV-over-IP transceiver wall plate (VGA & HDMI® inputs, white or black)

Features

4K visually lossless over 1Gbps network
Low 1.5 frame latency
1080p to 4K, 4K to 1080p scaling
HDMI® 2.0/HDCP 2.2
Secure Content Encryption
Unlimited scalability (based on network topology)
Videowall with image rotation
PoE (Power over Ethernet)
Stereo line I/O
RS-232 and IR Control Ports
Auto sense switching
USB 2.0 Host and Device Ports
Dante® IP audio option

商品說明

The VLX-TCW2V provides one of the most advanced IP Streaming solutions on the market utilizing Aurora’s IPBaseT® technology, which synergizes various IP/AV standards to work together as one. It is the industry’s first 4K UHD transceiver with only 1.5 frame (25ms) latency and visually lossless compression. The VLX-TCW2V has 1 VGA and 1 HDMI port. Using a transmitter (encoder) and receiver (decoder), respectively, used to be the standard – until now. The VLX-TCW2 Series can be set up as either one to make installation, inventory, and troubleshooting easier.

Note: The selected network switch needs to support: 1Gbps, Non-blocking IGMP & Jumbo Frame Packets. The raw network cabling as well as the patch cables are as important as the switch. When using copper, CAT5e, 6, or 6a cable is preferred for optimal performance and is important to follow the standard rules for running Ethernet cables. No sharp bends, coiling, putting near power lines, grouping tightly together with other LAN cables, etc. Shielding is not necessary but can be used for noisy environments.

VLX-TCW2V 提供市場上最先進的 IP 串流解決方案之一，利用 Aurora 的 IPBaseT® 技術，協同各種 IP/AV 標準，使其協同運作。它是業界首款擁有僅 1.5 幀（25 毫秒）延遲和視覺無損壓縮的 4K UHD 收發器。VLX-TCW2V 配備 1 個 VGA 端口和 1 個 HDMI 端口。使用發射器（編碼器）和接收器（解碼器）分別運作曾是標準，但現在不再如此。VLX-TCW2 系列可以設置為單一設備，簡化安裝、庫存管理和故障排除。

注意：選擇的網絡交換機需要支持：1Gbps、無阻塞 IGMP 和 Jumbo 幀封包。網絡佈線和跳線和交換機一樣重要。使用銅線時，建議使用 CAT5e、6 或 6a 以達到最佳性能，並且遵循以太網纜線佈線標準規範。避免急彎、纏繞、靠近電力線、與其他 LAN 線纏繞在一起等情況。雖然不需要屏蔽，但在噪音環境中可使用。

View More 點擊瞭解更多詳細信息
